Gold Cello Cable Kit
MAN-G-CEL-CBLKIT (Ver. 1.101)
www.elmomc.com
4
Chapter 1: Introduction
This document provides the wiring details for the cables used to connect Elmo's Gold Cello
servo drive with the end-user application. The servo drive-side pinouts are provided in the
Gold Cello Installation Guide.
The cables come in one length: 2 meters (6 ½ feet).
1.1. Cable Kit
The catalog number of the Gold Cello cable kit is CBL-GCELKIT.
NOTE:
It should be noted that this kit does not include any communication cables. Please purchase
these cables separately.
This cable kit includes the following cables:
ELMO Part Number Function
CBL-DFDBK Feedback Port A
CBL-GDCPORTB Feedback Port B
CBL-GDCPORTC Port C
CBL-GDCI/O I/O cable
CBL-CEL24 VL+ auxiliary supply
In addition, standard cables that are not included in the cable kit are used to connect to the
EtherCAT In, EtherCAT Out and Mini-USB B-type connectors.
NOTE:
The CAN Terminator (ELMO Part Number ACC-TRM-01) must be separately requested when
the servo drive is located at the end point of the customer network. For details of the
operation of the CAN Terminator please refer to Chapter 7:.
