Qty Code Description
In the unlikely event of missing or damaged parts, please
contact the customer service team on 08442 920000.
When
calling this number, please quote the part code
reference numbers shown in this leaflet when
requesting spare or replacement parts.
This assembly requires two
people.
A x20 Bolt (M8x30mm)
Fittings Checklist
C
x26 Spring Washer
D
Flat Washer
Additional Tools Required
H x1 Spanner
F x6 Nut (M8)
Qty Code Description
B
Bolt (M8x50mm) x6
General Hints & Tips
When fitting barrel nuts into
the panels, ensure they are
fitted the correct way so the
hole is facing towards the
intersecting hole.
Intersecting
Hole
Care & Maintenance
Crosshead Screwdriver
We recommend the bed is
assembled in the room it will
be located in.
x2 Flange Nut ( M6) G
Screw (50mm) x3
E
Allen Key (5mm) x1
I
J M attress Stopper (Double) x2
K Angle Bracket x2
x32
Page 2 of 6
(Single) x1
check that all bolts are still tight.
Please retain your Assembly Instruction and
tools provided, for future use. Periodically
