12
ENGLISH
TECHNICAL SPECIFICATION
DVA MS12
System Active Amps
Type of amplifier Digital – Class D
DIGIPRO G3 TM technology
RMS power 700W
Musical power 1400W
Frequency response (-6dB)
(-10dB) 45Hz-140Hz
40Hz-165Hz
Cover range Omnidirectional
Sound pressure (SPL) 131dB
Component parts 1 woofer 12” – VC 3”
Input sensitivity nominal 0dB
Input impendence
Balanced
Unbalanced
20Kohm
10Kohm
Power supply Auto-Range
100-120Vac 50-60Hz
220-240Vac 50-60Hz
Inrush current 17.9A
Current consumption
100-120Vac 50-60Hz
220-240Vac 50-60Hz
4A
2A
Dimensions (LxHxP) 460x430x385mm
18.1x16.9x15.2 inch.
Weight 26.2Kg
58.4lbs
DSP processor
DSP
Audio conversion AD/DA
Volume control
Crossover (24dB/Oct)
28/56bit
24bit/48KHz
Digital
110Hz/140Hz
Mechanical parts
Box material
Colour
Box internal reinforcement
Housing shape
Stirrup material
Handle
Frontal grille
Birch plywood
Black
Birch plywood
Rectangular
Steel
1 x each side
Performed sheet 1.5mm
with internal foam
EMI CLASSIFICATION
According to the standards EN 55103 this equipment is designed and suitable to operate in E3 (or
lower E2, E1) Electromagnetic environments.
