DVA MINI Digital Array System
9
ENGLISH
"Subwoofer Phase " section
11) “Phase” switch
This two-position switch permits turning the audio signal reproduced by the subwoofer by
180°.
Rotation makes it easier to optimize the reproduction of the low frequencies even in the most
difficult installation situations. After completing installation, play a piece of music and move the
switch to achieve the best sound reproduction at low frequencies.
Power supply section
12) "AUTO-RANGE” MAINS INPUT" POWER SOCKET
For connecting the power cable.
The connector used for mains connection is a POWER CON® (blue)
13) “MAINS OUTPUT LINK” RELAUNCH POWER SOCKET
For re-launching the mains power. The output is connected in parallel with input (11) and can
be used to power another amplified speaker.
The connector uses a POWER CON® (grey)
14) "MAINS FUSE" FUSE CARRIER
Mains fuse housing.
