Dakota Ultrasonics
6
The Display
The numeric portion of the display consists of 4 complete digits
preceded by a leading "1", and is used to display numeric values, as well
as occasional simple words, to indicate the status of various settings.
When the PR-8
2
is displaying thickness measurements, the display will hold
the last value measured, until a new measurement is made. Additionally,
when the battery voltage is low, the entire display will begin to flash.
When this occurs, the batteries should be replaced.
These eight vertical bars form the Stability Indicator. When the PR-8
2
is
idle, only the left-most bar and the underline will be on. When the tool is
making a measurement, six or seven of the bars should be on. If fewer
than five bars are on, the PR-8
2
is having difficulty achieving a stable
measurement, and the thickness value displayed will most likely be
erroneous.
