44
8 HD port HDMI Video signal output port
9 USB To connect USB mouse, Mobile HDD,USB Storage drive, etc.
10 ESATA port ESATA HDD port
Rear panel I/O port connection
Rear panel I/O port function is shown as follow:
Item No. Parameter Description
1 Alarm input Alarm input port, connected to the alarm
2 GND Ground port
3 Alarm output Alarm output port
4 RS-485 RS-485 output port, connected to the PTZ
Via Don Arrigoni, 5 24020 Rovetta S. Lorenzo (Bergamo)
http://www.comelitgroup.com e-mail: [email protected]
1 2 4 3
