CiDRA Sonar Process Monitoring System - Manual (Page 16)

20909-01C Rev 04 Page 6-4
All of the following signals are energy-limited for the TB8-xx-xx-xx-03 transmitter
only. For the TB8-xx-xx-xx-04 Transmitter they are not energy-limited.
Note: These signals are not present on every model. Some models may have one-
piece screw terminal blocks and others may have two-piece pluggable terminal
blocks with either screw or spring clip terminals. These terminals will accept 0.325
to 1.31 mm
2
(22-16 AWG) conductor sizes. Conductor size 0.52 mm
2
(20AWG) or
larger cross section is recommended.
I/O NAME OUTPUT IS LIMITED TO LIMIT INPUT TO
Sensor 1 - HI +12V, 48mA Passive 4-20mA transducer
Sensor 1 - LO -12V, 48mA Passive 4-20mA transducer
Sensor 1 - SHD Ground Ground shields at one end only
Sensor 2 - HI +12V, 48mA Passive 4-20mA transducer
Sensor 2 - LO -12V, 48mA Passive 4-20mA transducer
Sensor 2 - SHD Ground Ground shields at one end only
1 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
1 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
2 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
2 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
3 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
3 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
4 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
4 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
5 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
5 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
6 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
6 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
7 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
7 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
8 – WHT +/-8.5V, 43mA from Sensor Head Connect only to sensor head cable
8 – BLK +/-8.5V, 22mA from Sensor Head Connect only to sensor head cable
9 – WHT Ground Connect only to sensor head cable
9 – BLK Ground Connect only to sensor head cable
10 – WHT RS-485 bus levels Connect only to sensor head cable
10 – BLK RS-485 bus levels Connect only to sensor head cable
11 – WHT -12V nom (-14.25V max), 180mA Connect only to sensor head cable
11 – BLK Ground Connect only to sensor head cable
12 – WHT +12V nom (+14.25V max), 180mA Connect only to sensor head cable
12 – BLK Ground Connect only to sensor head cable
SHD Ground Use for drain wire of sensor head
cable
SHD Ground Use for orange communication
wire, if present.
SHD Ground Provisional
SHD Ground Provisional
Table 5 Sensor Connections
