GA-7VT600-P(-L) Motherboard
English
Step 5: Connect Ribbon Cables, Cabinet Wires and Power
Supply
Step 5-1 : I/O Back Panel Introduction
X
PS/2 Keyboard and PS/2 Mouse Connector
PS/2 Mouse Connector
(6 pin Female)
PS/2 Keyboard Connector
(6 pin Female)
¾
This connector supports standard PS/2
keyboard and PS/2 mouse.
X
Y
Z
[
Y
\
X
X
X
X
X
Y
[
Z
Z
Z
Z
Z
Y
Parallel Port and Serial Ports (COMA / COMB)
This connector supports 2 standard COM ports
and 1 Parallel port. Device like printer can be
connected to Parallel port; mouse and modem
etc. can be connected to Serial ports.
Parallel Port
(25 pin Female)
COMA
COMB
Serial Port (9 pin Male)
