chiliGREEN D915PGNL User Manual
Page 65
Technical Reference
Table 18. Back Panel Connectors Shown in Figure 17.
Item/callout
from Figure 17
Description
A
PS/2 mouse port (Green)
B
PS/2 keyboard port (Purple)
C
Parallel port (Burgundy)
D
Serial port A (Teal)
E
Audio line in/Retasking Port C (Light blue)
F
Audio line out/Retasking Port D (Lime Green)
G
Mic in/Retasking Port B (Pink)
H IEEE-1394a
(optional)
I
USB ports (two)
J
LAN
K
USB ports (two)
65
