Board, Dimensions, Technical reference 65 – chiliGREEN D945GBO User Manual
Page 65
Technical Reference
65
Ø 1.00
[0.039]
0.00
[0.00]
9.18
[0.36]
9.40
[0.370]
5.84
[0.23]
17.19
[0.677]
52.70
[2.075]
90.34
[3.557]
110.58
[4.354]
140.39
[5.53]
0.00
[0.00]
9.18
[0.361]
11.55
[0.455]
Pictorial
View
13.00 TYP
[0.512]
172.93 REF
[6.808]
169.98
+ 0.12
- 0.13
[6.692 ]
+ 0.004
- 0.005
OM18267
Figure 23. I/O Shield Dimensions for Boards without the Optional Parallel Port
