1 - 16 System Map: Right & Rear Views
Quick Start Guide
1
System Map: Right & Rear Views
Figure 1 - 8
Right & Rear Views
1.
Microphone-In
Jack
2.
Headphone-Out
Jack
3.
USB 2.0 Port
4.
Optical Device
Drive Bay (for CD/
DVD Device)
5.
Security Lock Slot
6.
Battery
Battery Information
Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See
for full in-
structions.
1
4
2
5
6
1
4
2
3
5
6
Model A
Model A
3
Models B & C
Models B & C
