Introduction
1 - 20 System Map
1
Rear View
RJ-11 Phone Jack
This port connects to the built-in modem. You may plug the tele-
phone line directly into this RJ-11 telephone connection.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN
port.
Figure 1 - 7
Rear View
1. RJ-11 Phone
Jack
2. RJ-45 LAN Jack
3. Parallel Port
4. Vent
5. External Monitor
(CRT) Port
6. S-Video Port
7. PS/2 Type Port
8. DC-In Jack
2
3
4
5
7 8
6
1
Overheating
To prevent your computer from overheating make sure nothing blocks the
vent while the computer is in use.
