Page 3

120 Volt
Standard
Cabinet
2100 Watts
120 volts
17.5 Amps
60 Hz
Single Phase
3
FEATURES & SPECIFICATIONS
Model
Number
Pan/Tray
Capacity
Adjustable spacing from
1.5” to 3” centers
12”x20” 18”x26”
Slide Pairs
Provided
Inside
Working
Height
in (mm)
Overall Dimensions
Height Depth Width
in (mm)
Caster
Diameter
in (mm)
Class 100
Shipping
Weight
lbs (kg)
HL10-5
(under-counter)
10 5
5
15-5/16
(389)
33-1/2 33-1/16 28 3/16
(851) (840) (716)
3
(76)
271
(123)
HL10-8
(
1/2 size)
16 8
8
24-15/16
(633)
45-1/2 33-1/16 28 3/16
(1156) (840) (716)
5
(127)
322
(146)
HL10-14
(3/4 size)
28 14
14
42-1/2
(1080)
64-3/8 33-1/16 28 3/16
(1635) (840) (716)
5
(127)
423
(192)
HL10-18
(full size)
36 18
18
54-1/2
(1384)
76-3/8 33-1/16 28 3/16
(1940) (840) (716)
5
(127)
495
(225)
Precision-engineered heat ducts with blower for even heat
and humidity. 90% humidity attainable at high tempera-
tures.
Digitally controlled and monitored heat and humidity levels
with autofill water connection.
Can be operated with or without humidity.
Low water indicator light and setting recovery button.
Under-counter, 1/2-size, 3/4 size and full size cabinets.
All swivel heavy-duty casters, front casters fitted with brakes.
Stainless steel doors are standard, optional clear doors —
field reversible.
Top-mounted enclosed water reservoir cannot be contami-
nated by food debris.
Off-the-shelf standard pan is easy to clean and inexpensive
to replace.
Adjustable universal stainless steel pan slides are standard;
Fixed angle slides for 18”x26” pans are optional
Top-mounted enclosed water reservoir
cannot be contaminated by food debris.
Off-the-shelf standard size pan is easy
to clean and inexpensive to replace.
Cabinets with Adjustable Universal Slides for 12”x20” Pans, 18” x 26” Trays and Gastronorm Pans
APPROVALS :
NSF/ANSI 4
Cabinet with Sliding Shelves for Pizza Boxes up to 16”, 16” Round Pans & 18”x26” Sheet Pans
Model
Number
Pan/Tray Capacity*
Pizza Boxes
or 16” 18”x 26”
Round Pans Trays
Shelves
Provided
in (mm)
Inside
Working
Height
in (mm)
Overall Dimensions
Height Depth Width
in (mm)
Caster
Diameter
in (mm)
Class 100
Shipping
Weight
lbs (kg)
HL10-36
36 18
18
56
(1422)
77-1/4 38-1/2 25-5/8
(1962) (978) (651)
5
(127)
529
(240)
* Channel slides fitted with wire pull-out shelves at
3” spacing.
Condensation drip trough
230 Volt
CE
Cabinet
2200 Watts
230 volts
9.7 Amps
50 Hz
Single
Phase
Plug cap per
specific
country
requirements/
standards
