Quick Start Guide
5 MC23-GB – v1.00
3 User levels
3.1 Understanding User Levels
There are two user levels in the controller; Level 1(Operator) and Level 2 (Supervisor).
Level 1 (Operator) is for the day to day operation of the controller. These parameters are
not protected by a security code.
Level 2 (Supervisor) provides access to additional parameters. Access to these is protected
by a security code
To Enter Level 2
1. Press and hold the page key

for 3 seconds.
2. The display will show
Leu 1
GOTO
3. Release the page Key
4. Press the Up

or Down

to choose
LEu 2 (level 2)
5. Press the Up

or Down

to enter the code (Level 2 Code = 9).
If the correct code is entered,
PASS should momentarily be displayed and then revert to the
level 2 home display (See Section Error! Reference source not found.)
If an incorrect code is entered the display reverts back to Level 1 home display (See Section
Error! Reference source not found.)
When level 2 operations have been completed, the supervisor must return to Level 1 either
manually or by ‘power cycling’, there is no time out function.
To Return to Level 1
1. Press and hold the page Key

2. Press Down

to select
LEu 1
It is not necessary to enter a code when going from a higher level to a lower level
When level 1 is selected, the display reverts to the home display (See Section 2.1)
Table showing parameters accessible in level 1 and Level 2
Operator LEVEL 1 Supervisor LEVEL 2
Home display Home Display
Alarms (if configured)
Comms (if configured)
Controller setup
TIP
If while navigating the controller a parameter has been passed or you need to access
parameters which would be at the end of a scroll list, press and hold Scroll

and use Up

to return to a previous parameter.
