CalDigit USB 3 card for desktop - Manual (Page 6)

Maximum Data Transfer Rate 5.0 Gigabits per Second
Interface to PC PCI Express 2.0 x 1
External Ports/Connections 2 USB 3.0 Ports (backwards compatible)
Operating System Support Windows XP/Vista/7 and Mac OS X
Dimensions 80 x 68.5 x 1.6mm (L x W x H)
Operating Temperature 32F ~ 104F
Storage Temperature -4F ~ 140F
Operating Humidity 0% ~ 80% RH, non-condensing
Express Card Diagram
Specifications
Optional: For extra power at
connectors, connect the 4 pin
power cable from your power
supply.
06
