8
DCX-900C Large Format Instructions 9-30-13
SECTION 3
Instructions for Slab Gel Electrophoresis
See Section 4 for casting gels using the Gel Wrap method. You may also use
the 4-place Multi-Caster DCX9-MC-4.
3.1 Preparing the Electrophoresis Unit
1. Power leads are shipped separately and
must be attached before using your
Large Format Cooled Vertical. Thread
the power lead ends into the lid recep-
tacles and rotate in clockwise direction to
hand tighten.
2. Place unit in authorized work area. Re-
move safety cover from the assembled
unit by simultaneously pressing down on
white push pins while lifting up on blue
safety cover as shown in figure 1.
Do not remove safety cover by pulling
up on leads!
3. Remove white core from lower reservoir
by grasping core with one hand and lifting
directly up as shown in figure 2.
4. Open doors on the core assembly by pull-
ing up on the white latches.
1
2
