SECTION 1
General Information
1.1 Introduction and Features
C.B.S. Scientific offers the Large Format Cooled Vertical is a temperature controlled
large capacity system for running SDS PAGE and 2-D analysis. The increased gel sizze
of 20cm(w) x 22cm(l) allows a larger sample volumes, increased number of wells and
longer migration distance.
Table 1: Features of DCX-900C
1.2 Specifications and Constructions
Constructions:
Buffer chamber, safety cover, core Polycarbonate/Polysulphone
Electrodes Pure Platinum wire .010” diameter
Power cords Silicone rated 7500VDC,
200mA, 65°C
Combs Teflon
Glass plates Soda-lime float glass & Borosilicate
Spacers PVC
Clamps Polypropylene, stainless steel
Safety Certification EN61010-1-1993 (IEC1010-1)
Table 2: Specifications
Model # DCX-900C
Shipping Weight 10 lbs
Overall Size W x D x H (cm) 24.2 x 12.4 x 27
Recommended buffer volumes:
Cathode reservoir
Anode reservoir
1 Liter
800mls (minimum) / 3.2 Liters (maximum)
Slab gel run time 30-90 minutes
Blot run time 60-90 minutes
Handcast glass plate size (W x H) 20cm x 22
Voltage limit 300 V
Model # Single or
Dual
Plate Dimensions
(w x h)
Cooling
DCX-900C Dual 20cm x 22cm Double-sided cooling
labyrinths
