Product characteristics

1) This product is a monitoring multi meter designed for 2003 or later Toyota CAN-bus or vehicles equipped with

1996 or later ISO14230 diagnostics connector.

2) Characteristics

a) Easy

installation.

Installation just by connecting to the vehicle diagnostics coupler.

b) 65,000 Color LCD screen and multi angle display.

Can be set on three different angles depending on the location of the installation.

c) Monitors a maximum of 29 items and able to display 6 monitored items simultaneously.

Monitored items are: Speed, RPM, Water Temp, Ignition Timing, Fuel Injection Time, Air Flow Voltage,

Outside Temp, Intake Manifold Pressure, Boost, O2 Voltage, O2 Rear Voltage, AF 1, AF 2, Intake Air Mass ,

Battery Voltage, Throttle Output, AT Temp, Gear Position, 4WD Ratio, Fuel Pressure, Momentarily Fuel

Consumption, Malfunction Diagnosis Code, Lock Up ON・OFF, External Voltage Input (Press, A/F Box) /

External Temp Input, Fuel Pressure Control, Fuel Injection Control / Electric Fan Control, etc

・ Depending on the vehicle, the monitored items vary or cannot be monitored.

・ The optional Press Sensor and (or) the A/F Box must be separately purchased to display the

external voltage input.

・ The optional Temp Sensor must be separately purchased to display the External Temp Input.

Temp Sensor Set

(Code: 19210)

130.00 USD

Press Sensor Set

(Code: 19211)

130.00 USD

retail price

d) Active Control Function

The Fuel Pressure, Fuel Injection and Electric Fan can be controller actively.

There are some vehicles that this function cannot be used.

The fuel pressure can be controlled every 100 RPM and can be increased of decreased from –9.9 to 25%.

The fuel injection can be controlled every 500 RPM within the 3000 RPM range and can be increased of

decreased up to ±25%.

The electric fan be controlled to go ON or OFF within 20 to 100℃ of the water temp.

e) Data Record and Play・Graphical Display

Maximum of 10 minutes recording time. Graphically displays the AF 1/ AF 2 and the external voltage input

based on RPM. (Useful for tuning)

※ Only the external voltage input can be displayed if the AF 1/ AF 2 cannot be monitored.
