PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E180 (cont)
LEGEND
566E180/524A-C180 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
4500
6000
7500
Evaporator Air — Ewb (F)
57
62
67
72
57
62
67
72
57
62
67
72
80
TC
180.0
190.0
206.0
223.0
197.0
201.0
216.0
233.0
209.0
210.0
222.0
239.0
SHC
180.0
162.0
136.0
110.0
197.0
188.0
156.0
122.0
209.0
208.0
174.0
134.0
kW
12.90
13.20
13.60
14.00
13.30
13.40
13.80
14.20
13.60
13.70
14.00
14.40
85
TC
177.0
187.0
203.0
220.0
194.0
198.0
212.0
229.0
206.0
206.0
219.0
235.0
SHC
177.0
160.0
135.0
109.0
194.0
186.0
154.0
121.0
206.0
206.0
173.0
132.0
kW
13.50
13.80
14.20
14.60
13.90
14.00
14.40
14.80
14.20
14.20
14.60
15.00
95
TC
172.0
180.0
195.0
212.0
188.0
190.0
204.0
221.0
199.0
199.0
210.0
226.0
SHC
172.0
157.0
132.0
106.0
188.0
182.0
151.0
118.0
199.0
199.0
169.0
129.0
kW
14.70
14.90
15.40
15.80
15.20
15.20
15.60
16.10
15.50
15.50
15.80
16.20
100
TC
169.0
176.0
191.0
207.0
184.0
186.0
200.0
216.0
195.0
195.0
205.0
221.0
SHC
169.0
155.0
130.0
104.0
184.0
180.0
149.0
116.0
195.0
195.0
168.0
128.0
kW
15.40
15.60
16.00
16.40
15.80
15.80
16.20
16.70
16.10
16.10
16.40
16.90
105
TC
166.0
172.0
187.0
203.0
181.0
182.0
195.0
211.0
191.0
191.0
201.0
216.0
SHC
166.0
153.0
128.0
102.0
181.0
178.0
147.0
115.0
191.0
191.0
166.0
126.0
kW
16.00
16.20
16.60
17.10
16.40
16.50
16.90
17.40
16.70
16.80
17.00
17.50
115
TC
159.0
164.0
178.0
193.0
173.0
174.0
185.0
201.0
183.0
183.0
191.0
205.0
SHC
159.0
149.0
124.0
98.8
173.0
172.0
144.0
111.0
183.0
183.0
162.0
122.0
kW
17.30
17.50
17.90
18.40
17.80
17.80
18.10
18.60
18.10
18.10
18.30
18.80
566E180/524A-B180 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
4500
6000
7500
Evaporator Air — Ewb (F)
57
62
67
72
57
62
67
72
57
62
67
72
80
TC
169.0
180.0
195.0
211.0
185.0
190.0
204.0
221.0
196.0
197.0
211.0
227.0
SHC
169.0
152.0
128.0
104.0
185.0
175.0
146.0
115.0
196.0
193.0
162.0
125.0
kW
12.70
12.90
13.30
13.70
13.10
13.20
13.50
13.90
13.30
13.30
13.70
14.10
85
TC
167.0
177.0
192.0
208.0
182.0
186.0
201.0
217.0
193.0
194.0
207.0
223.0
SHC
167.0
151.0
127.0
103.0
182.0
173.0
144.0
113.0
193.0
191.0
160.0
123.0
kW
13.30
13.50
13.90
14.30
13.60
13.70
14.10
14.50
13.90
13.90
14.30
14.70
95
TC
161.0
170.0
184.0
200.0
176.0
179.0
193.0
209.0
186.0
187.0
199.0
215.0
SHC
161.0
147.0
124.0
99.8
176.0
169.0
141.0
111.0
186.0
186.0
157.0
120.0
kW
14.50
14.70
15.10
15.50
14.80
14.90
15.30
15.70
15.10
15.10
15.50
15.90
100
TC
159.0
166.0
181.0
196.0
173.0
176.0
189.0
204.0
183.0
183.0
194.0
210.0
SHC
159.0
145.0
122.0
98.2
173.0
167.0
139.0
109.0
183.0
183.0
155.0
119.0
kW
15.10
15.30
15.70
16.10
15.50
15.50
15.90
16.40
15.70
15.70
16.10
16.50
105
TC
156.0
163.0
177.0
192.0
169.0
172.0
185.0
200.0
179.0
179.0
190.0
205.0
SHC
156.0
144.0
120.0
96.6
169.0
165.0
138.0
107.0
179.0
179.0
153.0
117.0
kW
15.70
15.90
16.30
16.80
16.10
16.20
16.50
17.00
16.40
16.40
16.70
17.20
115
TC
150.0
155.0
168.0
183.0
163.0
164.0
175.0
190.0
172.0
172.0
180.0
195.0
SHC
150.0
140.0
117.0
93.2
163.0
160.0
134.0
104.0
172.0
172.0
150.0
114.0
kW
17.10
17.20
17.60
18.10
17.50
17.50
17.80
18.30
17.70
17.70
18.00
18.50
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW
— Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC
— Total Capacity (1000 Btuh) Gross
