BASELINE Lift BLMC1500 - Manual (Page 9)

9
ITEM DESCRIPTION QTY
1 Small ramp(Right) 1
2 Connecting shaft 4
3 Small platform assy 1
4 Small ramp(Left) 1
5 Ramp 1
6 Support shaft assy 2
7 Side extension(Left) 1
8 Position pin 4
9 Thread shaft assy 1
10 Hex bolt 14
11 Fixed plate assy(1) 1
12 Fixed plate assy(2) 1
13 Flat washer 14
14 Limit shaft 1
15 Platform assy 1
16 Tool box 1
17 Side extension(Right) 1
18 Hex nut 14
19 Spindle(1) 2
20 Elastic washer 18
21 Frame assy(1) 1
22 Safety assy 1
23 Elastic spindle 2
24 Magnet 1
25 Hex bolt 2
26 Idler wheel 4
28 Spindle(4) 1
29 Frame assy(2) 1
30 Underframe assy 1
31 Spindle(2) 2
32 Spindle(3) 2
33 Cylinder assy 1
34 Oil hose 1
35 Gear pump 1
36 Gear pump cover assy 1
37 Piston rod assy 1
38 O-ring 1
39 Elastic washer 1
40 Dust ring 1
41 Cylinder cover 1
42 Position ring 1
43 Piston 1
44 Guide ring 1
45 O-ring 1
46 U-ring 1
47 Elastic washer 1
48 Cylinder jointing assy 1
49 Throttling valve assy 1
50 Red copper washer 1
51 Union 1
