SPECIFICATIONS:

Model

LSSMC1500

Capacity

1500lbs (680Kg )

Operating Pressure

0.8-1.0Mpa (116-145psi)

Lowered Height

11/16” (170mm )

Raised Height

38-

1/2” ( 980mm )

Platform (L x W)
(with extension)

88-

9/16” * 31-1/2” ( 2250mm * 800mm )

88-

9/16” * 50” ( 2250mm * 1270mm )

Shipping weight
(with extension)

462lbs ( 210Kg )
616lbs ( 280Kg)

FEATURES:

Made of Heavy-Duty Diamond Plate
Professional Air Hydraulic Pump with Protective Case
Extra-High 980mm ( 38-1/2") for Easy Service Operation
Extra-Wide Platform 800mm ( 31-1/2"). 1270mm ( 50") with Side Extensions
Single Hydraulic Lifting Cylinder
Cut-Out for easy access to rear wheel

STANDARD ACCESSORIES:

(1) 9-

1/4” (235mm) side extensions.

(2) Approach ramps for side extensions
(3) Four connecting rods to support the side extension.
(4) Set of pins to secure the rods
(5) Rear poles for fixing the motorcycle on platform
(6) Front Wheel Vise
