Vision ® 5X4 Exploded View
Part Number Description
02-OP 0.04”Thick Inside or Outside Cover Plate for 4X5 or 5X4 Helmets
02-OP-AF 0.04”Thick Inside or Outside Anti-fog Cover Plate for 4X5 or 5X4 Helmets
03-OP 0.04”Thick Inside or Outside Cover Plate for 2X4 Helmets
08-IP 0.03”Thick Inside Cover Plate for 4X5 or 5X4 Helmets
02-HG Economical Ratchet Headgear with Cloth Sweatband
06-HG ComfaGear Ratchet Headgear with Deluxe Sweatband
SPR-01 Small Springs for Hawk
® Helmets (10 pack)
SPR-02 Large Springs for Viper
®
, Vision
®
, and Eagle
® Helmets (10 pack)
For additional parts and accessories, visit our website and view our online brochure at
www.arc1weldsafe.com.
Table 1: Parts Selection Guide
Outside Cover Plate
Helmet Shell
AD Filter
Inside Cover Plate
Mag Lens (Optional)
Headgear Assembly
