Aquascape Waterfall Spillway (77000) User Manual

Waterfall spillway

(Item #77000)

Waterfall Spillway

Installation Instructions

PACKAGE INCLUDES

Instructions

The Waterfall Spillway is a cost-effective solution to help you create beautiful waterfalls and streams. This

compact, yet extremely strong Waterfall Spillway is positioned at the starting point of the waterfalls. The pipe

from your waterfall pump is connected to the back of the Waterfall Spillway where the incoming rush of water

is diffused by internal barriers. These barriers help calm the water, providing a smooth flowing waterfall

through the front of the spillway. The liner is attached to the Waterfall Spillway using the two rubber gaskets

and retaining nut located on the back of the Spillway.

Item#77000

Made In U.S.A.

Aquascape, Inc.

St. Charles, IL 60174 • Brampton, ON L6T 5V7

www.aquascapeinc.com

• Waterfall Spillway
• 2” MPT x Slip
• Instructions

Step 1.

Build Waterfall and stream providing enough liner at the top of the waterfall to wrap over the top of the Wa-

terfall Spillway. For information on waterfall and stream design and installation please visit our video gallery at

www.aquascapeinc.com.
Step 2.

Set the Waterfall Spillway into desired location.

Adjust the height of the Waterfall Spillway to match the starting point of the waterfall. A

bed of gravel can be placed on top of the liner, beneath the Waterfall Spillway to raise the height

of the spillway to the desired level.

The gravel will also provide a suitable base for leveling the Waterfall Spillway. The Waterfall Spill-

way should be level from side to side and tilt forward a ¼ bubble on a 2 foot level.
