• Life Expectancy
Life expectancy of the NLS varies with applications such as corrosive vapor,
temperature, microswitch’s load, etc.
Since the NLS is not in contact with the liquid, it can be used for a long time.
Replace expendable diaphragms and microswitches.
• Spare Parts
Model Description Part Number
NLS-ACC1 Neoprene diaphragm for NLS-1A 22907-0022
NLS-ACC2 Viton diaphragm for NLS-1S 22907-0023
NLS-ACC3 Neoprene diaphragm for NLS-3 22907-0024
NLS-ACC4 Microswitch assy for NLS-1A 22907-0085
NLS-ACC5 Microswitch assy for NLS-1S 22907-0086
NLS-ACC6 Microswitch assy for NLS-3 22907-0087
