NLS Series Rev. A1, 4/07
4
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Specifi cations
Operational Versions
NLS-1A: Standard media
NLS-1S: Corrosive media
NLS-3: Economic, light duty
Characteristics
Detection Range: 8-200 in. (200- 5000 mm)
Operating Point 1 : 80 ± 10 mm (NLS-1A) (SG = 1.0)
70 ± 10 mm (NLS-1S) (SG = 1.0)
65 ± 10 mm (NLS-3) (SG = 1.0)
Release Point 2 : 60 ± 15 mm (NLS-1A) (SG = 1.0)
50 ± 15 mm (NLS-1S) (SG = 1.0)
50 ± 15 mm (NLS-3) (SG = 1.0)
Max. Viscosity: 10 P (1/2 in. pipe); 30 P (1 in. pipe);
100 P (2 in. pipe); 250 P (5 in. pipe).
Switch Rating: 250 V 10 A AC; 115 V 0.5 A DC;
(Resistive Load) 230 V 0.05 A DC
Physical Attributes
Enclosure Protection: IP23 (NLS-1A); IP20 (NLS-1S; NLS-3)
Material:
Housing Cover: ADC (NLS-1A; NLS-1S); SS41 (NLS-3)
Housing: ADC (NLS-1A; NLS-1S); phenolic (NLS-3)
Chamber: ADC (NLS-1A); SCS13 (NLS3); phenolic (NLS-3)
Diaphragm; Neoprene (NLS-1A); NLS-3); Viton (NLS-1S)
Cable Entry: G 3/4 (NLS-1A); rubber bushing: (6 mm dia. hole)
Mounting: G1 male
Pipe Coupling: R 1/2 female
Notes:
1 Operating point means the position whereat the switch assumes ON as a
result of rise of level, such position being represented by dimensions from
the pipe end.
2 Returning point means the position whereat the switch assumes OFF as a
result of fall of level, such position being represented by dimensions from
the pipe end.
