Rev. A1, 4/07 NLS Series
5
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Installation
Unpacking
When unpacking, do not damage the sensor with mechanical shock. After
unpacking, make sure that products you ordered are complete. If any part is
missing, wrong or damage, please contact APG.
Installation
Install the sensor in an area which meets the following conditions:
• The ambient temperature range is 0 to +70°C (32 to 160°F).
• Humidity and vibration are low.
The NLS sensor should be installed in an area which meets the following
conditions:
• The ambient temperature range: 32 to 160°F (0 to 70°C).
• Located away from splashing liquid.
• No corrosive gases (such as NH
3
, SO
2
, CL
2
, etc.) present.
• Low humidity and vibration.
• Open container in nonhazardous area.
• Ample space for maintenance and inspection.
Install the NLS vertically from the container top. Provide a G 1 in. female
boss on the container top. Be sure to use a suitable gasket, O-ring, or thread
tape.
