PT-400

Rev. C, 4/13

4

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

• Description

The PT-400 offers high accuracy and reliability over a wide range of pressures.
The small size, integrated electronics, wide operating temperature range, and
durability, make the PT-400 the perfect instrument for static and dynamic
pressure m easurements with an amplified output signal.

Electrical ratings; 9 to 28 Volts DC, 4 - 20 ma / 0-5VDC (per order)

Exia Class I Division 2; Groups C, D T4
Class I, Zone 2, Group IIB
AEx nC IIB T4: Ta: -40°C to 85°C
Ex nL IIB T4: Ta;. -40°C to 85°C

PT-400-L1 (4-20ma)
Vmax Ui= 28VDC, Imax Ii = 110ma, Pmax Pi = 0.77W, Ci = 0.055uF, Li = 7.95uH

Install in accourdance with drawing 9002794 (page 9).

PT-400-L3/L10 (0-5V/0-10V)
Vmax Ui= 28VDC, Imax Ii = 110ma, Pmax Pi = 0.77W, Ci = 0uF, Li = 0uH

Install in accourdance with drawing 9002794 (page 10 & 11).

Electrical ratings; 9 to 28 Volts DC, 4 - 20 ma / 0-5VDC (per order)

Exia Class I Division 1; Groups C, D T4
Class I, Zone 0, Groups IIB
AEx ia IIB T4: Ta: -40°C to 85°C
Ex ia IIB T4: Ta: -40°C to 85°C

Vmax Ui= 28VDC, Imax Ii = 110ma, Pmax Pi = 0.77W, Ci = 0.055uF, Li = 7.95uH

Install in accourdance with drawing 9002794 (page 8).

The following approvals only apply to the L1 or 4-20mA version

ATEX Directive:

0334

Sira 13ATEX 2023

II 1G Ex ia IIB T4 Ga

-40°C

≤ Ta ≤ +85 °C

Ui

≤ 30 V, Ii ≤ 110 mA, Pi ≤ 1 W,

Ci

≤ 60.89 nF, Li ≤ 10.95 uH

IECEx CSA 13.0004

Ex ia IIB T4 Ga

Install in accourdance with drawing 9002460 (page 8).

All repairs and adjustments of the PT-400 must be made by the factory. To
modify, disassemble, or alter the PT-400 on site is strictly prohibited.
