WELCOME TO
EFFICIENT HOME
COOLING COMFORT
Congratulations on your excellent choice
and sound investment in home cooling
comfort!
Your new air conditioning unit represents
the culmination of many years of experi-
ence from one of the most reputable man-
ufacturers of comfort systems.
Your new unit is among the most reliable
and energy-efficient air conditioning
products available today. To assure its
dependability, spend just a few minutes
with this booklet now. Learn about
the operation of your air conditioner,
and the small amount of maintenance
it takes to keep it operating at its peak
efficiency.
With minimal care, your new air condi-
tioner will provide you and your family
with cool comfort—both now and for
years to come.
SAFETY
CONSIDERATION
Recognize safety information. This is the
safety-alert symbol
. When you see
this symbol on the unit or in instructions
and manuals, be alert to the potential for
personal injury.
Understand the signal word DANGER,
WARNING, or CAUTION. These words
are used with the safety-alert symbol.
DANGER identifies the most serious
hazards which
will
result in severe per-
sonal injury or death. WARNING signi-
fies hazards that
could
result in personal
injury or death. CAUTION is used to
identify unsafe practices which
would
result in minor personal injury or product
and property damage
.
WARNING
Improper installation, adjust-
ment, alteration, service, main-
tenance, or use can cause
explosion, fire, electrical shock,
or other conditions which may
cause personal injury or prop-
erty damage. Consult a quali-
fied installer, service agency, or
your distributor or branch for
information or assistance. The
qualified installer or agency
must use factory-authorized
kits or accessories when modi-
fying this product.
!
!
YOUR COMFORT
SYSTEM
Identifying Your System
Take time to get to know the type of
system you have. This will be helpful in
understanding the basic operation of your
new air conditioner.
The split-system type has an indoor and
an outdoor unit, each of which contains a
coil. These units are interconnected by
refrigerant tubes. (See Fig. 1.)
Each unit has a rating plate affixed to it
which provides necessary information
for specific identification of a unit. You
should familiarize yourself with the
product, model, and serial numbers listed
on each rating plate. Record them for
future reference on last page of this
booklet.
IMPORTANT FACTS
To better protect your investment and to
eliminate unnecessary service calls,
familiarize yourself with the following
facts:
Keep Filter Clean
Your air conditioning system should never
be operated without a properly installed,
clean air filter. Plan to inspect the filter
periodically. A clogged air filter will
increase operating costs and shorten the
life of the unit.
Do Not Block Registers
Supply-air and return-air registers should
not be blocked. Drapes, furniture, and
toys are some of the items commonly
found obstructing registers. Restricted
airflow lessens the unit’s efficiency and
life span.
Do Not Cover or Block
Outdoor Unit
The outdoor unit must have unrestricted
airflow. Do not cover the unit, lean any-
thing against it, or stand on it. Do not
allow grass clippings, leaves, or other
debris to accumulate around or on top of
the unit. Maintain a 12-in. minimum
clearance between the outdoor unit and
tall grass, vines, shrubs, etc.
Get To Know Your
Thermostat
Your multipurpose indoor thermostat is
the control center for your air condition-
ing system. You should familiarize
yourself with its proper operation.
Attempting to control the system by other
means—for instance, switching the
electrical supply power ON and OFF—
may cause damage to the unit.
Thermostat “jiggling” causes rapid-
cycling, which is potentially damaging
to the compressor. Do not move the
temperature selector on the thermostat for
any reason for at least 5 minutes after the
compressor has shut off.
Continuous Fan
You may find that you can maintain
greater personal comfort by running the
fan continuously. Air pockets can form
due to the structure of the house,
placement of registers, etc. These air
pockets may be too cool or warm for your
liking. Continuous fan operation
minimizes temperature differences.
WARNING
To prevent personal injury,
death, or property damage,
read and follow all instructions
and warnings, including labels
shipped with or attached to unit
before operating your new air
conditioner.
!
•
•
•
•
•
Fig. 1—
Typical
Split-
System
Installation
