CONTENTS
Thank you for purchasing your Allen & Heath ZED mixer. To ensure that
you get the maximum benefit from the unit please spare a few minutes
familiarizing yourself with the controls and setup procedures outlined in
this user guide. For further information please refer to the additional
information available on our web site, or contact our technical support
team.
http://www.allen-heath.com
http://www.allen-heath.com/zed
http://www.myspace.com/thezedspace
Warranty ............................................. 3
Packed Items....................................... 4
Safety Instructions ............................. 5
Contents.............................................. 7
Panel Drawings................................... 8
Introduction to ZED ......................... 11
Specifications ...................................... 12
Dimensions ......................................... 13
Block Diagram.................................... 14
Mono Input Channel ......................... 15
Stereo Input Channel........................ 19
Matrix Outputs & Aux Masters....... 22
Group Masters ................................... 23
L R & M Masters & Headphones .... 24
Main Meters and Talkback ................ 25
USB Selection and Playback............. 26
USB Connection ................................ 27
SONAR LE software introduction . 28
SONAR LE installation ..................... 29
Configuring SONAR LE with ZED. 29
Using USB for effects ........................ 32
Wiring Notes ..................................... 33
Product Support ................................ 34
