Allen & Heath 29 ZED-4 BUS User Guide
System Requirements.
SONAR LE Installation.
Put disk into CD or DVD ROM drive and follow instructions on screen!
SONAR LE Audio Configuration with ZED.
To configure your SONAR LE software to communicate audio to and from your ZED mixing console, follow the se-
quence below.
Ensure the ZED mixing console is powered on.
Connect the USB lead from the computer to the USB port on ZED.
First check that your computer has recognised
the connection of the ZED USB device by clicking
Settings/Control Panel/Sounds and Audio Devices.
The device name should be USB Audio CODEC
(ensure there are no other external audio devices
attached to the computer).
Also ensure the Device Volume is set to High.
This can default to the middle during connection
which means very low volume from the USB device, so
it’s worth checking the first few times you connect.
The properties window should look like this:
It is also a good idea to select “No Sounds” in the
Sounds window.
System Require-
ments Minimum Recommended
Operating System Windows XP Windows XP/Vista/Vista x64
Processor Speed Intel® Pentium® 4 1.3 GHz,
or AMD™ Athlon XP 1500+
or higher
Intel® Pentium® 4 2.8 GHz
[EM64T], or AMD™ Athlon 64
2800+or higher
RAM 256 MB 1 GB or higher
Graphics (resolution,
color depth) 1024 x 768, 16-bit color 1280 x 960, 32-bit color
Hard Disk Space 100 MB for core program 2 GB for program and content
Hard Disk Type Any EIDE/Ultra DMA (7200 RPM) or
SATA
MIDI Interface Windows-compatible Windows-compatible
Audio Interface Windows-compatible WDM- or ASIO-compatible, includ-
ing WaveRT for Vista
Optical Drive DVD-ROM, DVD+/-R, or DVD+/-RW for installation, CD-R or CD-
RW capability required for CD audio disc burning
