6
INTRODUCTION TO THE XONE:23
The Xone:23 is a high performance 2+2 channel VCA mixer designed around
the latest analogue circuitry featuring microprocessor control of all signal
routing.
It is equipped with a version of the famous Xone filter system, a 3 band EQ
Isolator, plus a send/return loop for external effects.
The crossfader curve has two settings, suitable for either blending or beat
matching, or a more aggressive curve for scratching. For ultimate crossfader
performance the mixer can also be equipped with a custom Innofader,
available from your nearest Allen & Heath stockist, (part number
004-504JIT).
With a studio standard 20dB of signal headroom, a separate booth monitor
and balanced XLR main outputs, (with an impressive +28dBu max level) the
Xone:23 is perfect for the DJ who requires a high quality compact mix tool.
Key features of the Xone:23 are:
 2+2 stereo channels with dual levels for phono/line inputs
 Up to 4 sources can be mixed simultaneously
 3 Band full cut equalizer
 Voltage Controlled Filter system
 Send/Return loop for external FX
 Accurate signal level monitoring with peak hold
 Main mix outputs on professional balanced XLR connectors
 Dedicated local monitor (booth monitor)
 Pro standard headroom (+20dB) to prevent overload
 +28dBu maximum output level (balanced XLR)
 Low audio distortion (typically 0.01% at +10dBu output)
 Dedicated record output
 Crossfader curve switch
 Innofader crossfader option
 Cue mix control with illuminated Cue switches
 UV sensitive ink screen for improved low light legibility
 Universal voltage power supply (works anywhere in the World)
We wish you the same fun playing on it as we have had designing it!
