33
T
HE
P
ATCH
D
ISPLAY
N
ORMAL
M
ODE
Shows selected patch number
0
to
127
or
ALL
Indicates which patch which will overwrite the console mutes
when you press RECALL, or be overwritten when you press
STORE. The ACTIVE PATCH dot tells you how the
displayed number relates to the current console mute settings:
ACTIVE PATCH on :
Displayed patch is the last patch recalled.
Console mutes are the same as the displayed patch (except
for channels made 'safe').
ACTIVE PATCH off :
Displayed patch is the last patch recalled.
Console mutes have changed since the patch was recalled.
ACTIVE PATCH flashing :
Displayed patch is not the same as the last patch recalled.
This is always the case in 'auto-increment' mode where the
display automatically steps up ready for recall.
C
LEAR
OR
S
ET
ALL
M
UTES
Flashes
CLr
or
SEt
to warn that all console mutes will
be turned on or off when this function is selected.
C
ONSOLE
M
ODE
The MODE dot turns on.
2 digit code indicates the selected console mode. Digit 3
shows if the mode is selected ( = ) or not ( ).
MIDI C
HANNEL
N
UMBER
The MIDI CHANNEL dot turns on.
The display indicates the console MIDI channel number
selected. This can be channel
1
to
16
or
OFF
S
OFTWARE
V
ERSION
N
UMBER
Refer to the section on TECHNICAL SUPPORT.
E
RROR
C
ODES
Displays the error number and code referenced in the
section on TECHNICAL SUPPORT.
