Allen&Heath MixWizard3 12-2 User Manual
Page 5

WZ
3
16:2
and
12:2
User Guide
5
Introduction
Welcome to the Allen & Heath WZ
3
, the latest generation of the popular MixWizard series of
compact audio mixing consoles. We have tried to keep this user guide brief and to the point.
Please read it fully before starting. Included is information on installing, connecting and
operating the console, panel drawings, system block diagram and technical specification.
For further information on the basic principles of audio system engineering, please refer to
one of the specialist publications and resources available from bookshops, audio equipment
dealers and the Internet.
Whilst we believe the information in this guide to be reliable we do not assume responsibility
for inaccuracies. We also reserve the right to make changes in the interest of further product
development.
We are able to offer further product support through our world-wide network of approved
dealers and service agents. You can also access our Web site on the Internet for
information on our full product range, our company pedigree, assistance with your technical
queries, our contact details or simply to chat about matters audio (
www.allen-heath.com
)To
help us provide the most efficient service please keep a record of your console serial
number, and date and place of purchase to be quoted in any communication regarding this
product.
Note: This user guide refers to models equipped with a revised effects engine. This is
identified by a change from green to yellow effects preset indicators, and a change of serial
number from prefix W31202 to W31222, or W31602 to W31622. Note that these effects are
not compatible with the original WZ Effects Editor PC software. Refer to the Allen & Heath
web site for further information.
Contents
Warranty ................................................ 2
General Precautions.............................. 4
Introduction to this Guide...................... 5
Front Panel Layout ................................ 6
Introducing the MixWizard .................... 7
Installing the Console............................ 8
Connecting Power................................. 9
Connecting a Backup Supply ............... 9
Connection Pinouts and Cables ......... 10
Audio Connections.............................. 11
Connector Panel Layouts.................... 12
Console Connectors............................13
Mono Input Channel............................15
Stereo Input Channel...........................17
Stereo Effects Channel........................18
Master Section.....................................19
Gain Structure......................................21
Specifications ......................................22
System Block Diagrams ......................24
User Options........................................26
Cue Sheets ..........................................29
