STEP 13
Remove dust cover by using 5/16” nutdriver or socket. Remove paper tape from winch drum while keeping
tension on winch cable.
Never operate the ALL200 without tension on the cable. Never remove or tamper with the cable safety
device. Never install an ALL200 that has the cable safety device removed or tampered with. The cable
safety device consists of the limit switch and small gauge rectangular wire. It is located directly in front
of the winch drum. Removing or tampering with the cable safety device could cause the cable to become
reversed wrapped on the winch. This could also cause the cable to unravel off the winch drum and get
damaged. Never install or operate an ALL200 that has a frayed, kinked, or otherwise damaged cable.
Never operate the ALL200 without first removing the paper tape from the winch drum. Avoiding any of
these safety warnings could cause the chandelier to fall, which could cause death, personal injury, and/or
property damage.
STEP 14
Replace dust cover by fastening the two 5/16” self tapping screws. Locate controller wire. Controller wire is
a low voltage, gray sheathed, four conductor wire with white plugs on either end.
STEP 15
Run controller wire in to single gang box for Keyswtich Controller or optional SmartLift Controller.
Chandelier must be visible from controller location.
STEP 16
If using a Keyswitch Controller instead of a SmartLift Controller, secure key cylinder to cover plate using
supplied keyswitch nut.
Plug controller to controller wire. Use supplied cover plate screws to attach controller to single gang box.
STEP 17
Test motor and automatic shut-off system of ALL200. For operation instruction, reference Keyswitch
Controller Guide or SmartLift Controller Guide, then follow below:
Run ALL200 down one meter. Run ALL200 up to CEILING POSITION. When ALL200 pulls bottom
contact plate and temporary weight to CEILING POSITION, the motor will, if installed and mounted
properly, shut off by itself.
Call Aladdin Light Lift (877) 287-4601 immediately if ALL200 does not shut off at CEILING
POSITION.
Never extend the full length of winch cable from the ALL200. This could cause the cable to become
reverse wrapped on the winch. An ALL200 installed with a reverse wrapped cable can cause the
chandelier to fall, which could cause death, personal injury, and/or property damage. Refer to the
Keyswitch or SmartLift Controller tag for correct operating instructions. Winch cable length can be
found on the ALL200 product sticker, shipping box and the front page of these installation instructions.
STEP 18
Run ALL200 down until temporary weight is at desired elevation to hang chandelier.
STEP 19
Holding tension on cable, unscrew weight from fixture coupler.
Never operate the ALL200 without tension on the cable. This could cause the cable to wind off the
winch drum and get damaged. A damaged cable could cause the chandelier to fall, which could cause
death, personal injury, and/or property damage.
