AirLive Traveler 3G II User’s Manual
52
redirected to the computer specified by the Server IP. Virtual Server can work
with Scheduling Rules, and give user more flexibility on Access control. For
Detail, please refer to Scheduling Rule.
For example, if you have an FTP server (port 21) at 192.168.123.1, a Web
server (port 80) at 192.168.123.2, and a VPN server at 192.168.123.6, then
you need to specify the following virtual server mapping table:
Port Server IP Enable
21 192.168.123.1 V
80 192.168.123.2 V
1723 192.168.123.6 V
Click on “Save” to store what you just select or “Undo” to give up
