Unpacking and Installation
This chapter provides unpacking and installation information for the Switch. To avoid
causing any damage to the Switch, we recommend that you read this chapter carefully
before starting installation.
Unpacking
When unpacking the product package, you shall find these items listed below.
z
19” Media Converter Chassis System
z
One power supply installed on the chassis
z
One AC power cord
z
User’s
Manual
z
Accessories: rackmount screws (8 pcs) & rackmount ears (2 pcs) rubber foot (4 pcs)
If any item is found missing or damaged, please contact your local reseller for
replacement.
Installation
The site where you place the chassis system may greatly affect its performance. When
installing, take the following into your consideration:
A
S WITH ANY ELECTRIC DEVICE
,
YOU SHOULD PLACE THE EQUIPMENT WHERE IT WILL NOT BE
SUBJECTED TO EXTREME TEMPERATURES
,
HUMIDITY
,
OR ELECTROMAGNETIC INTERFERENCE
.
S
PECIFICALLY
,
THE SITE YOU SELECT SHOULD MEET THE FOLLOWING REQUIREMENTS
:
The ambient temperature should be between 32 and 104 degrees Fahrenheit (0 to 40
degrees Celsius).
The relative humidity should be less than 90 percent, non-condensing.
Surrounding electrical devices should not exceed the electromagnetic field (RFC)
standards for IEC 801-3, Level 2 (3V/M) field strength.
Make sure that the equipment receives adequate ventilation at the rear. Do not block
the fan exhaust holes on the rear of the chassis.
The power outlet should be within 1.8 meters of the chassis.
Deciding How to Install the System
We strongly suggest that you install the chassis first, as this is more convenient for you to
install media converters into the chassis with ease. The accessories supplied in the
product package includes: rackmount screws(8 pcs) and rackmount brackets(2 pcs). This
well-built chassis can be installed in the following ways:
.Mounted to 19-inch standard rack
Use the rackmount brackets and screws to install the chassis into any EIA 19” standard
rack.
