AirLive ePhone-1000S - Manual (Page 38)

- 38 -
※ When operating H.323 Protocol, you may enter the IP address instead of a
phone number to create an entry when there is no gatekeeper or a voice
gateway. Please use “*” instead of “.” when inputting an IP address. For
example 192.168.1.21 should be entered as 192*168*1*21.
Nat Traversal Function
AirLive ePhone-1000 Supports Nat Traversal Functions。
STUN
server address：Enter SIP Server IP address or Domain
nat traversal：Select STUN
nat addr：Enter STUN server IP address or Domain
OutBound Proxy
server address：Enter outbound proxy IP or Domain. Fill-in the port number is the UDP port is not 5060.
service id：Enter SIP proxy IP or Domain
nat traversal：Select disable
Registration Message
When the registration for AirLive ePhone-1000 is successful, Ready for Call
will appear on the screen. If the registration is not successful hand Log fail or
Wait Log will appear.
