SmartyCam
User Manual
Release 1.22 – firmware version 1.03.10
9
www.smartycam.com
1.2 – SmartyCam Bridges kits
There are two available Briges for SmartyCam: ECU Bridge and RPM Bridge.
1.2.1 – ECU Bridge kits
There are two available ECU Bridges, required to connect SmartyCam to the vehicle
ECU. Their part number changes according to the communication protocol they are
equipped with.
• ECU Bridge with CAN/RS232 communication protocol: X90BGGPI2R
• ECU Bridge with CAN/K Line communication protocol: X90BGGPI2K
Each ECU Bridge kit includes:
1 – ECU Bridge
1 – USB cable.
Refer to
www.smartycam.com , accessories area for further information concerning ECU
Bridges.
1.2.2 – RPM Bridge kit
RPM Bridge is needed to view RPM values on SmartyCam videos. The kit includes:
• RPM Bridge
• USB cable
RPM Bridge kit part number is: X90BGGP3RPM
Refer to
www.smartycam.com , accessories area for further information concerning RPM
Bridge.
