Industrial PCs MCR5000
© ads-tec GmbH • Raiffeisenstr.14 • 70771 Leinfelden-Echterdingen
25
5
I
NTERFACES
5.1
230
V
AC
POWER SUPPLY
The voltage is supplied through a rubber connector.
The MCR 5000 is equipped with an AC IN socket, through which the voltage can be supplied
to the device. Additionally, the MCR 5000 device is equipped with an AC OUT socket, which
allows supplying external devices. If the MCR 5000 is attached to a monitor, the monitor can
also be supplied through the AC OUT socket of the MCR 5000.
T
ECHNICAL DATA OF THE POWER ADAPTER
•
Power consumption:
Max. 72 Watts
•
Input voltage:
90…264 V AC
•
Mains frequency:
47…63Hz
•
Current consumption:
1.85A
•
Max. switch-on current:
100A (230V AC)
Warning:
The load at the switched AC power supply output must not exceed 500W.
AC out: Max. 5A / 100V, max. 2.1A / 240V
