Industrial PCs MCR5000
© ads-tec GmbH • Raiffeisenstr.14 • 70771 Leinfelden-Echterdingen
17
I
NSTALLING THE INSTALLATION BRACKET
The installation bracket including 6 x M6 screws must be screwed to the monitor according
to the instructions of the monitor manufacturer.
Horizontal installation:
Warning:
All six screws must be used for fixing the installation bracket.
Warning:
The permissible thread depth of the fixing screws inside the monitor case has to be
checked before installing the bracket on the monitor.
