PAS-225VPB MAINTENANCE
© 11/2013 ECHO Inc.
X7722275104 29
Nylon Line Replacement
Wear Gloves or personal injury may result:
• Cutoff knife is sharp.
•
Gearcase and surrounding area may be hot.
1. Cut one piece of line to recommended length.
.080 (2.0 mm) dia. – 20’ (6 m)
.095 (2.4 mm) dia. – 20’ (6 m)
2. Align arrows on top of knob with openings in eyelets.
3. Insert one end of trimmer line into an eyelet, and push line
equal distance through trimmer head.
4. Hold trimmer head while turning knob clockwise to wind line
onto spool until about 5” (13 cm) of each line remains
exposed.
Trimmer head is now fully loaded and ready for operation.
When the wear indicators located at the bottom of the
Speed-Feed® head are worn smooth, or if holes appear,
replacement of the cover or the entire Speed-Feed® head is
required.
For more information
scan this QR code.
Wear Indicators
