26
s
pecIfIcatIons
MODEL ---------------------------------------------------- SHC-225, SHC-225S
Length (SHC-225) --------------------------------------- 1810 mm (71.3 in.)
Length (SHC-225S) -------------------------------------- 1480 mm (58.27 in.)
Width (SHC-225) ----------------------------------------- 246 mm (9.69 in.)
Width (SHC-225S) ---------------------------------------- 246 mm (9.69 in.)
Height (SHC-225) ----------------------------------------- 290 mm (11.4 in.)
Height (SHC-225S) ---------------------------------------- 290 mm (11.4 in.)
Weight (dry) (SHC-225) ---------------------------------- 6.35 kg (14.0 lb.)
Weight (dry) (SHC-225S) -------------------------------- 6.17 kg (13.6 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 32.2 mm (1.27 in.)
Stroke -------------------------------------------------------- 26.0 mm (1.02in.)
Displacement ----------------------------------------------- 21.2 cc (1.29 cu. in.)
Exhaust ------------------------------------------------------ Spark arrestor - catalytic muffler / muffler
Carburetor--------------------------------------------------- Zama Diaphragm w/Purge Pump
Ignition System -------------------------------------------- Flywheel Magneto, CDI (capacitor discharge ignition) with ESG
Spark Plug -------------------------------------------------- NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ---------------------------------------------- 50 : 1 Power Blend X™ ISO-L-EGD (ISO/CD 13738) and
J.A.S.O. M345- FC/FD, two-stroke, air-cooled engine oil.
Gasoline ----------------------------------------------------- Use 89 Octane unleaded. Do not use fuel containing methyl
alcohol, more than 10% ethyl alcohol or 15% MTBE. Do not use
alternative fuels such as E-20 or E-85.
Oil ------------------------------------------------------------ Power Blend X TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.44 lit. (14.9 US fl. oz.)
Recoil Starter System ------------------------------------- Automatic Recoil Starter
Clutch-------------------------------------------------------- Centrifugal Type
Gear Case Ratio ------------------------------------------- 5.88:1
Cutter ------------------------------------------------------- Double Reciprocating Blade - Double Edge
Length ----------------------------------------------------- 515 mm (20.28 in.)
Pitch ------------------------------------------------------- 35 mm (1.4 in.)
Maximum Diameter Cut
Soft Material ---------------------------------------------- 25.4 mm (1 in.)
Woody Material ------------------------------------------- 13 mm (1/2 in.)
Idle Speed --------------------------------------------------- 2,500 - 3,000 RPM
Clutch Engagement Speed -------------------------------- 4,100 RPM
Wide Open Throttle Speed ------------------------------- 10,600 - 11,600 RPM
