9 5 INCH CHIPPER
ENGLISH
Section
1. Read and understand all safety warnings and chipping
guidelines contained in this manual before proceeding.
2. Connect PTO driveline to tractor as described in Sec.
2.4.
3. Adjust three-point top link so the chipper sits level.
4. Make sure the feed roller bar is in the Stop position. The
controller will flash red until the bar is in Stop. See Sec.
6 for a table of all flash codes for the controller light.
5. Start tractor engine and engage PTO (refer to tractor
owners manual). Increase engine speed to rated PTO
RPM until the controller light on the feed chute is
showing a steady green light.
6. Engage the hydraulic feed by moving the hydraulic
feed control arm. The control arm has four positions:
Reverse, Forward, Stop, and Reverse.
7. Feed branches up to five inches in diameter into the
chipper.
8. Reverse the feed by moving the control arm to reverse
position if the chipper jams. Remove the branch and
rotate it before reinserting it into the chute.
9. Adjust the speed of the feed roller, if necessary, with
the flow control knob.
4
OPERATION
4.1 STARTING THE CHIPPER
4.3 OPERATING THE CHIPPER
NOTE
The heavy rotor will continue to turn for some time after
the engine or tractor has been shut off. You can tell
that the rotor has stopped when no noise or machine
vibration is present. Inserting a branch into the chipper
chute to contact the blades will slow the rotor and
shorten stopping time.
4.2 STOPPING THE CHIPPER
1. Move tractor throttle to SLOW position.
2. Disengage PTO lever and shut off tractor engine.
3. Allow machine to come to a complete stop.
WARNING
Move machine to a clear, level area outdoors before
starting. Do not operate in the vicinity of bystanders.
Make sure cutting chamber is empty before starting.
WARNING
Before operating your machine, be sure you read
and understand all safety, controls and operating
instructions in this owner’s manual and on your
machine. Failure to follow these instructions can
result in serious injury or property damage.
DANGER
Do not inspect or work on PTO drive area without
first disengaging PTO and shutting off tractor. Allow
all moving parts to come to a complete stop.
CAUTION
Obtain and wear safety glasses at all times when
operating the machine.
Do not wear loose fitting clothing.
The operator should always wear heavy boots, gloves,
pants and a long-sleeved shirt.
Use common sense and practice safety to protect
yourself from branches, sharp objects, and other
harmful objects.
WARNING
Read and follow all safety instructions in this manual.
Failure to operate the machine in accordance with
the safety instructions MAY RESULT IN PERSONAL
INJURY!
