23 TURNTABLE CHIPPER
sPecificaTions
76824 & 76824s - 24 hP
descriPTion english meTric
OvERALL SIzE 93"x 80" x 90" 241.3cm x 203.2cm x 228.6cm
OvERALL WEIghT 2,250 lbs.(76824) 2,320 lbs. (76824s) 1021kg (76824) 1052kg (76824s)
MAx ChIppER CApACITy 8" dia. 20cm dia.
FEED ChUTE OpENINg 30-1/4" x 30-3/4" 76.8cm x 78.1cm
FEED TABLE 38" long 96.5cm long
ChIppER BLADES 4 reversible heat treated (5.09"x4"x0.375") 12.9cm x 10cm x 0.95cm
ChIPPING ANVIl (AdjUsTABle) 9.25" L x 3.5" W x 5/8" thick 23.49cm L x 8.89cm W x 1.59 cm thick
DISC SpEED 1500 RpM 1500 RpM
DISC SIzE 30" dia. x 1-1/4" thick 76.2 dia. x 3.175cm thick
DISC WEIghT 275 lbs. 125kg
DISChARgE BLOWER DIAMETER 8" 20cm
DISChARgE BLOWER hEIghT 95" 2.41m
DRIvE TypE Belt Belt
BELT SIzE Triple Banded Triple Banded
WhEEL BASE 75.13" 190.8cm
TIRE SIzE p215/70R15 or ST225/75R15
jACK (AdjUsTABle) 850 lb. rating 372 kg rating
ENgINE honda 24hp Electric honda 24 hp Electric
FUEL TANk CApACITy 10 gal. 37 liters
hyDRAULIC FEED RATE 0-155 feet/min (100 feet/min average) 0-47 meters/min (30 meters/min average)
hyDRAULIC OIL TANk CApACITy 3 gal. 11.5 liters
7.1 size sPecificaTions
76835, 76835s & 76835f - 35 hP
descriPTion english meTric
OvERALL SIzE * 93"x 80" x 90" 241.3cm x 203.2cm x 228.6cm
OvERALL WEIghT * 2,290 lbs.(76835) 2,350 lbs. (76835s) 1039kg (76835) 1066kg (76835s)
MAx ChIppER CApACITy 8" dia. 20cm dia.
FEED ChUTE OpENINg 30-1/4" x 30-3/4" 76.8cm x 78.1cm
FEED TABLE 38" long 96.5cm long
ChIppER BLADES 4 reversible heat treated (5.09"x4"x0.375") 12.9cm x 10cm x .95cm
ChIPPING ANVIl (AdjUsTABle) 9.25" L x 3.5" W x 5/8" thick 23.49cm L x 8.89cm W x 1.59 cm thick
DISC SpEED 1500 RpM 1500 RpM
DISC SIzE 30" dia. x 1-1/4" thick 76.2 dia. x 3.175cm thick
DISC WEIghT 275 lbs. 125kg
DISChARgE BLOWER DIAMETER 8" 20cm
DISChARgE BLOWER hEIghT 95" 2.41m
DRIvE TypE Belt Belt
BELT SIzE Triple Banded Triple Banded
WhEEL BASE 75.13" 190.8cm
TIRE SIzE p215/70R15 or ST225/75R15
jACK (AdjUsTABle) 850 lb. rating 372 kg rating
ENgINE B & S 35 hp Electric B & S 35 hp Electric
FUEL TANk CApACITy 10 gal. 37 liters
hyDRAULIC FEED RATE 0-155 feet/min (100 feet/min average) 0-47 meters/min (30 meters/min average)
hyDRAULIC OIL TANk CApACITy 3 gal. 11.5 liters
section
7
* does noT aPPlY To f models
