Installation – IOGear GCS712U User Manual
Page 11
3
4
8
Installation
Step 1.
Before you begin, please turn off the computers you are going to connect to the MiniView™
Micro USB Audio Switch.
NOTE:
To prevent damage to your equipment due to static electric discharge, please make sure that all devices
on the installation are properly grounded.
Connect your monitor to the female VGA port on your
MiniView™ Micro USB Audio.
Connect your PS/2 keyboard into the PS/2 keyboard
port on your MiniView™ Micro USB Audio.
Connect your PS/2 mouse into the PS/2 keyboard port
on your MiniView™ Micro USB Audio.
Connect your speakers directly into the audio port on
your MiniView™ Micro USB Audio.
1.
2.
3.
4.
