IOGear GCS1204G User Manual
Page 11
10
11
No.
Component
Description
1
USB Console Ports
USB Keyboard and mouse connections
2
Console Port Section
Monitor, mic, and speaker connections
3
CPU Port Section
Connections for the cables that link the switch to your computers.
Each CPU port is comprised of a microphone jack, speaker jack,
USB type B socket and a DVI connector
4
Power Jack
Power adapter connection
5
USB Peripheral Port
Connection for USB 2.0 peripherals ( printers, scanners, etc)
