SECTION 1 - SPECIFICATIONS
3121108 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 SPECIFICATIONS
1.2 CAPACITIES
1.3 COMPONENT DATA
Engine
Table 1-1. Operating Specifications
Machine Weight 7330 lbs (3324.8 kg)
Machine Height:
Fully Elevated
Stowed
26 ft (8 m)
7.5 ft (2.3 m)
Machine Width 5.9 ft (1.8 m)
Machine Length 8.9 ft (2.7 m)
Platform Railing Height 43.5 in. (1.1 m)
Platform Dimensions 8.5 x 5.4 ft (2.59 x 1.65 m )
Platform Capacity 1250 lbs (570 kg)
Platform Extension Capacity 300 lbs (140 kg)
Max Travel Speed 2.8 mph (4.5 kmh)
Max Travel Grade 35%
Max Slope:
Side to Side
Fore & Aft
3°
5°
Turning Radius:
Inside
Outside
6.9 ft (2.1 m)
14.4 ft (4.4 m)
Lift Speed: (no load)
Dual Fuel:
Up
Down
Diesel:
Up
Down
25-29 sec
21-27 sec
32 - 34 sec
21 - 27 sec
Max Tire Load 2600 lbs (1180 kg)
Max Ground Bearing Pressure 33 psi (2.3 kg/cm²)
Max Hydraulic system Pressure 3000 psi (20.68 Mpa)
Electrical System Voltage 12 Volt
Wheelbase 78 in. (2 m)
Ground Clearance 8 in. (20.3 cm)
Max Windspeed 28 mph (12.5 m/s)
Max Horizontal Manual Side Force 90 lbf (400 N)
Number of Persons 2
Table 1-2. Capacities
Fuel Tank 7.2 gal (27.2 L)
Hydraulic Oil Tank 15 gal (56.8 L)
Hydraulic System (including tank) 18 gal (68.1 L)
Engine Crankcase:
Gasoline Engine
Diesel Engine
3.4 qts (3.25 L)
4.2 qts (4 L)
Engine Coolant:
Gasoline Engine
Diesel Engine
1.25 gal (4.7 L)
1.5 gal (5.7 L)
Table 1-3. WG750-B Kubota Gasoline/LP
Type 3 cylinder, liquid-cooled
Power 24.5 horsepower @ 3600 rpm
Idle 1500 rpm
High Engine 3600 rpm
Alternator 40 Amp
Fuel Consumption:
Low RPM
High RPM
1.3 gph (4.9 Lph)
2.4 gph (9 Lph)
Table 1-4. DF752-E2 Kubota Gasoline/LP (Tier 3)
Type 3 cylinder, liquid-cooled
Power 24.8 horsepower @ 3600 rpm
Idle 1500 rpm
High Engine 3600 rpm
Alternator 40 Amp
Fuel Consumption:
Low RPM
High RPM
1.3 gph (4.9 Lph)
2.4 gph (9 Lph)
The Altitude Compensation Kit on this TIER 3 engine is
set up from the factory to EPA emission standards for
altitudes below 2800 ft. (700m). Kits for operating at
higher altitudes are available from Kubota.
If operating at higher altitudes without the proper kit
installed, this engine will run with a rich fuel mixture
and may therefore exhibit the following issues:
• Excessive exhaust temperature: This may rapidly
or immediately damage the catalyst (if equipped).
Engine overheating may also occur.
• Excessive soot: This will rapidly deteriorate the
engine oil, the valves, and the exhaust ports with
carbon deposits. If enough soot is built up the cata-
lyst (if equipped) may not function properly.
• Emissions: Kubota cannot guarantee emissions
without the proper Altitude Compensation kit
installed.
