SECTION 1 - SPECIFICATIONS
3121154 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
Hydraulic Oil Capacity
System Capacity – 5 qts. U.S. (4.7 ltr.)
Reservoir Size – 148 cu. in. (2.56 qts. U.S.) (2.42 Liter)
minimum usable
1.2 COMPONENT DATA
Hydraulic Pump/Electric Motor Assembly
AC Models - 120/240 Volt AC motor/pump
Motor - 100/200 - 230V-AC, 1HP, 2850/3450 RPM, 50/
60Hz
Pump Displacement – AFC 0.077 cu. in./rev. (1.26 cc/
rev.)
Pump Output – 1.37 GPM @ 1350 PSI @ 15 AMPS @
115v-AC @ 45 Centistrokes (200 SSU)
Pressure Relief – Adjustable Range 1500 PSI (103.4 Bar)
to 5000 PSI (344.7 Bar), Set to 1700 PSI (117.2 bar),
adjust to lift maximum rated capacity.
1.3 PERFORMANCE DATA
Machine Specifications
1.4 TORQUE REQUIREMENTS
When maintenance becomes necessary or a fastener has
loosened, refer to the Fastener Torque Charts in this sec-
tion to determine proper torque value per the size and
grade of the fastener.
SPECIFICATION 15BD 19BD
Maximum Occupants: (Persons) 1
Maximum Work Load
(Platform Capacity):
350 lb. (160 kg)
Machine Stowed Height: 77.22 in.
(1.96 m)
77.81 in.
(1.97 m)
Machine Stowed Width:
29.75 in. (75.5 cm)
Maximum Vertical Platform Height
(Ground to Platform Floor - Platform
Fully Extended):
15.25 ft.
(4.65 m)
18.75 ft.
(5.72 m)
Maximum Step-in Platform Height
(Ground to Platform Floor - Platform
Fully Lowered):
12.75 in. ( cm) 13.37 in. ( cm)
Working Height: 21 ft.
(6.4 m)
24.75 ft.
(7.54 m)
Standard Platform Size: 27 in. x 23 in.
(68.5 cm x 58.5 cm)
Platform Speed (seconds) Lift Up: 20 22
(w/max. rated load) Lift Down: 32 - 40 18 - 25
Machine Weight (Platform Empty ): 725 lb.
(329 kg)
830 lb.
(376 kg)
System Voltage: 12V DC/120 Volts-60Hz AC
Machine Base Mounting Footprint: 18 in. x 33 in.
(45.72 cm x
83.82 cm)
0.75 Dia. Holes
20 in. x 24 in.
(50.8 cm x
60.96 cm)
0.75 Dia. Holes
