2-12 1532E/1932E/2033E/2046E/2646E/2658E 3120847
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
Note: To determine Power or Gravity Down refer to page A.
HYDRAULIC COMPONENTS INSTALLATION Ref.
(VARIABLE PARTS)
0257210 2033E (VARIABLE PARTS) Ref. 4/B
0257212 2046E/2546E/2658E Ref. 4/B
51 4845366 Tray Weldment 1
4845366 2033E
4849875 2046E/2546E/2658E
SIDE COVERS INSTALLATION - 2033E Ref.
0258182 2033E Ref. 1/A
0255939 2046E/2646E Ref. A
0255940 2658E Ref. A
101 Cover Options: 1
4060937 2033E
3539446 2046E/2646E
3539447 2658E
102 Hardware Options: 4
3941406 2033E (Screw, Self Tapping 1/4"-20 x 3/4")
0641408 2046E/2646E/2658E (Bolt 1/4"-20NC x 1")
103 4751400 Flatwasher - 1/4" A/R
104 3311405 Locknut - 1/4"-20NC A/R
FIGURE 2-4. HYDRAULIC COMPONENTS AND COVERS INSTALLATION - 2033E/2046E/2646E/
2658E (GRAVITY DOWN MACHINES) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
