3120847 1532E/1932E/2033E/2046E/2646E/2658E 3-37
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-10. ARM GUARDS INSTALLATION - 2033E/2046E/2646E BUILT PRIOR TO S/N 30542
AND ALL 2658E BUILT PRIOR TO S/N 51216
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0256629 ARM GUARDS INSTALLATION - 2033E/2046E/2646E BUILT Ref. 3/C
PRIOR TO S/N 30542 AND ALL 2658E BUILT PRIOR TO
S/N 51216
1 Not Used
2 0256616 Actuator Assembly (Rear) (See Items 101-118 For 1
Breakdown)
3 0480094 Belt, Mesh - End 2
4 0181888 Angle, End 2
5 0641406 Bolt 1/4”-20NC x 3/4” 26
6 4711400 Flatwasher 1/4” Narrow 52
7 3311405 Locknut 1/4”-20NC 26
8 0181889 Angle, Side 2
9 0480092 Belt, Mesh - Side 2
10 4240033 Tie-Strap 82
11 0480093 Belt, Mesh - End 1
12 0256615 Actuator Assembly (Front) (See Items 101-118 For 1
Breakdown)
13 3539897 Plate, End Tray 1
14 4845372 Tray - Side 2
15 3539907 Tray - End 1
16 0641608 Bolt 3/8”-16NC x 1” 6
17 4711600 Flatwasher 3/8” Narrow 12
18 3311605 Locknut 3/8”-16NC 6
19 to 23 Not Used
24 4420055 Tape, UHMW 6in/15cm
25 3520072 Plug, Tube 2
ACTUATOR ASSEMBLIES
0256615 Front Actuator Ref. 2
0256616 Rear Actuator Ref. 3
101 Tube - Outer Options: 1
4567062 Front Actuator
4567067 Rear Actuator
102 Tube - Inner Options: 1
4567060 Front Actuator
4567075 Rear Actuator
103 4160136 Spring, Gas 2
104 0641509 Bolt 5/16”-18NC x1” 2
105 0100011 Loctite #24231 (Not Shown) A/R
106 4845370 Link 1
107 3340781 Pad 2
108 0641604 Bolt 3/8”-16NC x 1/2” 8
109 4751600 Flatwasher 3/8” 8
110 4761600 Lockwasher 3/8” 8
111 0641516 Bolt 5/16”-18NC x 2” 1
112 4751500 Flatwasher 5/16” 4
113 3311505 Locknut 5/16”-18NC 2
114 3340780 Pad 4
115 0641536 Bolt 5/16”-18NC x 4 1/2” 1
116 0962074 Bushing 1
117 0962075 Bushing 1
118 3900213 Screw, Button Head 3/8”-16NC x 3/8” 4
